HARLEY RONDA 1063 Swiss Quartz Movement Gold 5 jewels 3Hands

Features – Repairable metal watch movement – Power saving mechanism with pullled out stem: Reduction of consumption approximately 70% – Complete interchangeability between 1062-1064 Hands: Hours, Minutes, Seconds Description Cal. 1063; 6 3⁄4 x 8 ’’’; height 1.90 mm Slimtech movement series; extra small and slim movements. Available in ‘Swiss Made’ (5 jewels) and ‘Swiss Parts’ (1 jewel) version. Sold individually Outside Diameter: 6 3/4 x 8 Ligne or 15.3 x 17.8mm Movement 1.95mm thick The height from the bottom of the watch movement to the top of the sweep second pinion is 3.3mm Hour wheel is 1.05 mm tall Requires watch cell 321 Requires watch hands: hour 1.20, minute .70, and sweep second .20mm Has 1 jewel Stem: 401-1478, tap 10 Includes watch stem Harley Ronda quartz movement Swiss parts Technical Specifications Diameter Total 15.30 mm Case fitting 15.30 mm Movement height 1.90 mm Height over standard battery 1.95 mm Height over high battery 2.55 mm Movement rest 0.40 mm Height over stem 0.75 mm Length of stem travel 0.35 mm Force to push the stem for screwed crown N Stem thread 0.90 mm Standard battery 321 High battery 364 Standard battery life 25 months High battery life 34 months Battery voltage 1.5 V Current consumption – typical 0.82 μA Current consumption – maximum 1.15 μA Useful torque second – typical 5 μNm Useful torque minute – typical 250 μNm Operating temperature 0 – 50 °C Instantaneous rate -10/ 20 sec/month Resistance to magnetic fields 18.8 Oe Resistance against shock NIHS 91-10
